Application:Liquid ,Oil, Water
Range:300--3000mm
Connection:Thread ,Flange
Power supply:24VDC
Display:LCD display
Output:4-20mA
Communication:RS485 ,HART Customized
Temp:70degC ,120degC,200degC
Work pressure:0.6--2.5Mpa
IP grade:IP65
Material:Staniless steel ,PTFE
Exproof:ExiaIIC T6 (Customized)
Warranty:12months
Inquiry

DESCRIPTION :

Float level transmitter consists of two parts: liquid level sensor and current converter. Float and liquid level are changed synchronously,

and the reed switch is controlled to be closed and shut down, so the internal resistance of the sensor becomes linear, so that the switch

is then the inverter converts the change in resistance in the standard current signal 4-20 mA and of a digital signal output. It can display,

alert and control the liquid level of medium in the hole, sealed container or underground tank in the air. The detected environment can be

water, oil, acid, alkali, industrial waste water and other conductive and non-conductive liquids, and can overcome the influence of the

false Liquid Liquid Liquid Liquid It is widely used in oil refining, chemical, paper, food and cleaning industry.

MAIN TECHNICAL DATASHEET :

Application

Liquid,Oil,Water

Measuring range

300-3000mm

Connection

Thread,Flange

Power Supply

24VDC

Output Signal

4-20mA

Operating temperature

≤80C; ≤120C; ≤150C

Work Pressure

0.6-2.5Mpa

IP grade

IP65

Material

Stainless Steel,PTFE

Accuracy

0.5%FS

Explosion-proof grade

ExiaIIC T6 (Customized)
