| Principle: | Turbine transducer | |
| Material: | Stainless steel 304 ,316L | |
| Connection: | Thread ,Flange ,Triclamp ,Insertion | |
| Diameter: | DN2--DN300 mm | |
| Output: | Pulse, 4--20mA output | |
| Display: | English LCD display | |
| Accuracy: | +_0.5 +_0.2 +_1 | |
| Power supply: | 24VDC ,Lithium Battery | |
| Medium: | Liquid | |
| Pressure: | 1.6Mpa---35Mpa | |
| Standard: | G , BSP, NPT, ANSI, DIN ,JIS | |
| Warrany: | 12 months | |
| Brand: | XINSIER | |
| Inquiry | ||
DESCRIPTION :
Turbine flowmeters are widely used in flow measurement: petroleum, organic liquids, inorganic liquids, liquefied gas, natural gas, coal gas and cryogenic fluids. Turbine flowmeter signals can be divided into pulse signals or current signals (4-20mA). It is suitable for use with secondary display, PLC, DCS and other computer control systems.
FEATURES :
LWGY turbine flow transducer adapts to measure the liquid rate and total flowrate of low viscosity.It can be widely used in the fields of Petrol,
Chemicial industry,Metallurgy,Scientific reaserch for measuring or control.Several output an display methods can be selected.
High accuracy, good repeatability, low pressure loss, good vibration resistance;
Adopt high-quality bearings with low friction resistance. Good sealing and long life;
It integrates microprocessor, flow sensor, high-precision temperature and pressure sensor. Directly measure the flow, temperature and pressure of the gas/liquid being measured. And automatically perform flow tracking compensation and compression factor correction operations;
The meter has pulse signal and analog signal output. It can directly realize the centralized collection and real-time management of computer data through the RS485 communication interface .
Low power consumption. It can be powered by internal battery or external power supply;
With real-time data storage function. It can prevent data loss when the battery is replaced or the power is suddenly lost. In the case of power failure, internal data can be stored permanently;
SPECIFICATIONS :
High-accuracy:+-0.5% , +-0.2% , +-1%
Wearable Tungsten carbonized shaft and bearing,be the same with the medium of sully
Erode-resistant appliable for sea water ,ammonia,actometer,etc
Bi-direction measuring bi-direction flow (optional)
Multi-output pulse,4—20mA DC, total and rate display in the field
Power supply 5—24V DC
Explode-proof Ex d II BT4/Ex ib I / CT6
Spectrum 2” 4” 6,10,15,25,40,50,80,100,150,200,250,300mm
Medium temperature:--20centigrade to +120 centigrade (150 centigrade)
Environment temperature: --25centigrade to +55 centigrade
Max Pressure loss:0.025 Mpa for above DN50
Normal Pressure:1.6Mpa 2.5Mpa 4.0Mpa 6.3Mpa and customized
Flange :GB , DIN , JIS , ANSI can be negotiable
Material: Stainless steel 304 , Stainless steel 316 can be negotiable
More flow range ，connection mode , pressure rate can be customized .
Reference flow range for initial reference only :
MAIN TECHNICIAL DATASHEETS :
DN (mm) | Minimum Flow rate Unit :m3/h | Maximum Flow rate Unit :m3/h | Accuracy % | Connection Size（negotiable） | Nominal Pressure (Mpa) |
2 | 0.01 | 0.13 | +_1% | G 1/4” | 1.6 |
4 | 0.04 | 0.25 | +_1% | G 1/4” | 1.6 |
6 | 0.1 | 0.6 | +_1% | G 3/8” | 1.6 |
10 | 0.2 | 1.2 | +_0.5% | G 1/2” | 2.5 |
12 | 0.25 | 2.5 | +_0.5% | G 1/2” | 2.5 |
15 | 0.4 | 4 | +_0.5% | G 1” | 2.5 |
20 | 0.7 | 7 | +_0.5% | G1 1/4” | 2.5 |
25 | 1 | 10 | +_0.5% | G1 1/4” | 2.5 |
32 | 1.5 | 15 | +_0.5% | G 1 1/2” | 2.5 |
40 | 2 | 20 | +_0.5% | G2” | 2.5 |
50 | 4 | 40 | +_0.5% | Flange | 2.5 |
65 | 6 | 60 | +_0.5% | Flange | 1.6 |
80 | 10 | 100 | +_0.5% | Flange | 1.6 |
100 | 20 | 200 | +_0.5% | Flange | 1.6 |
150 | 40 | 400 | +_0.5% | Flange | 1.0 |
200 | 80 | 800 | +_0.5% | Flange | 1.0 |
250 | 120 | 1200 | +_0.5% | Flange | 1.0 |
300 | 180 | 1800 | +_0.5% | Flange | 1.0 |
